SMT PCB Cutter

Model:OB-C668P

Brand:OUBEL

Delivery date:20-25 working days

Description

SMT PCB Cutter is Used for cutting PCB/LED board in SMT Production Line

Leave message

Leave message

Be the first to messgae “SMT PCB Cutter”

Your email address will not be published.

Description

SMT PCB Cutter

Features

1. PCB board does not move in the cutting process, and the round knife slips to ensure that electronic components are not damaged due to movement;

2.The cutting speed can be adjusted, and the plate stroke can be set, which can be displayed by LCD screen;

3.The distance between upper round knife and lower straight knife is adjustable;

4.Three groups of safety sensors protect the operator, and the height of the front and rear table can be adjusted in parallel.

Specifications

Dimension 460*780*560mm
Maximum cutting length 460mm
Cutting speed 100/200/300/500mm/s
PCB thickness 0.6-3.5mm
Voltage 220v
Weight 55kg
